Edelbrock Super Victor II Intake Manifold for Standard Deck Chevrolet Big-Block V8
Edelbrock part #2896 Super Victor II is designed for use with large cubic inch big-block Chevy engines using the latest design conventional port heads. These single-plane intake manifolds are ideal for any 1,000+ horsepower drag race engine with high air flow requirements. The Edelbrock Super Victor II #2896 intake manifold features an improved runner design with an incredible 5.0 square-inches of runner area in the plenum. Accepts standard height distributors. This manifold has an extra large carburetor outer flange with a 5" x 5" opening to fit high flow carburetors and throttle stops.
Application Summary:
| Year |
Make/Model |
| Chevrolet:Big-Block |
Race:- |
| Attributes |
| ASIN |
B006MYBTWG |
| Basic Operating RPM Range |
3500-8500 |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Center Maximum Height |
7.560, 7.56 |
| CNC Ported |
No |
| Country of Origin (Primary) |
US |
| Cylinder Head Type |
Rectangular Port |
| EGR Port |
No |
| Emission |
N/A, Without EGR |
| Emission Code |
Off Road |
| Engine Make/Size |
Chevy Big Block (396-502) |
| Finish |
Satin, Satin, Satin |
| Flange Type |
4500 |
| Front Maximum Height |
7.560, 7.56, 7.560 |
| Gasket Or Seal Included |
No, No, No |
| Grade Type |
Performance, Performance, Performance |
| Harmonized Tariff Code (Schedule B) |
8708998175 |
| Hazardous Material Code |
N |
| Life Cycle Status Code |
Available to Order |
| Material |
Aluminum, Aluminum, Aluminum |
| NAFTA Preference Criterion Code |
B |
| Number of Carbs |
One |
| Position |
N/A |
| Potential Risk Chemical |
Lead |
| Rear Maximum Height |
7.560, 7.56, 7.560 |
| RGL |
WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov., WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| RPM Range |
3500-8500 |
| SDR Required Flag |
N |
| SDS Sheet Number |
NA |
| Series |
Victor, Victor |
| Single Or Dual Plane Type |
Single Plane, Single Plane, Single |
| Usage |
Racing |
| Vehicle Model |
Chevrolet, Chevrolet |
| Warranty Time |
12 |
| GTIN |
00085347028962 |
