Edelbrock Super Victor 23 Degree Intake Manifold For Chevrolet 262-400 Small-Block V8
Edelbrock part #2925 Super Victor 23-degree intake manifold is designed for heads with a standard port location, the runners match the "flat floor" entry of the latest 23-degree heads. Carb pad height is 5-1/2" (from end seals) and overall, this intake is about one-inch taller than our Victor Jr. intake #2975. Runners have a 2.80 square-inch cross-section.
Application Summary:
| Year |
Make/Model |
| Chevrolet:Small-Block |
Gen I:262 (4.3L)/265 (4.3L)/267 (4.4L)/283 (4.6L)/302 (4.9L)/305 (5.0L)/307 (5.0L)/327 (5.4L)/350 (5.7L)/400 (6.6L) |
| Attributes |
| ASIN |
B00062Z318 |
| Basic Operating RPM Range |
3500-8000 |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Center Maximum Height |
5.500, 5.5 |
| CNC Ported |
No |
| Country of Origin (Primary) |
US |
| Cylinder Head Type |
Raised Port 23 Degree |
| EGR Port |
No |
| Emission |
Without EGR |
| Emission Code |
Off Road |
| Engine Make/Size |
Chevy Small Block (262-400) |
| Finish |
Satin, Satin, Satin |
| Flange Type |
4150 |
| Front Maximum Height |
5.500, 5.5 |
| Gasket Or Seal Included |
No, No, No |
| Grade Type |
Performance |
| Harmonized Tariff Code (Schedule B) |
8708998175 |
| Hazardous Material Code |
N |
| Life Cycle Status Code |
Available to Order |
| Material |
Aluminum, Aluminum, Aluminum |
| NAFTA Preference Criterion Code |
B |
| Number of Carbs |
One |
| Position |
N/A |
| Potential Risk Chemical |
Lead |
| Rear Maximum Height |
5.500, 5.5, 5.500 |
| RGL |
WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov., WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| RPM Range |
3500-8000 |
| SDR Required Flag |
N |
| SDS Sheet Number |
NA |
| Series |
Victor, Victor |
| Single Or Dual Plane Type |
Single Plane, Single Plane, Single |
| Usage |
Racing |
| Vehicle Model |
Chevrolet, Chevrolet |
| Warranty Time |
12 |
| GTIN |
00085347029259 |
